Single Inlet Combustible Gas Delivery Centrifugal Ventilation Fans
Introduction
Medium requirements for 6-08 series fans: The medium to be
transported should be non-corrosive, non-flammable, explosive, and
free of viscous substances. The dust and hard particles contained
in the medium should be no more than 150mg/m3.
Medium temperature: The medium temperature of standard fans is not
more than 80 °C, the V-belt driving type fan can transport media
below 150 °C for a long time when it is added to the
heat-dissipating wheel.
It is widely used in environmental dust removal, material
transportation, and industrial equipment.
Technical data
| series | model | Rotation Speed
(r/min) | Total Pressure
(Pa) | Air Capacity
(m³/h) | Power
(kW) |
|---|
| 6-08 | 8D | 1450 | 1859～2745 | 11000～26400 | 15 ~ 22 |
| 9D | 1450 | 2353～3474 | 15700～37500 | 30 ~ 45 |
| 10D | 1450 | 2905～4289 | 21500～51500 | 45 ~ 75 |
| 11D | 960 ~ 1450 | 1541～5190 | 22700～68500 | 22 ~ 110 |
| 12D | 960 ~ 1450 | 1834～6176 | 24600～89000 | 37 ~ 160 |
| 13D | 960 ~ 1450 | 2152～7248 | 31200～113000 | 55 ~ 250 |
| 14D | 960 ~ 1450 | 2496～8406 | 39000～141000 | 75 ~ 400 |
| 15D | 730 ~ 1450 | 1657～9650 | 36600～172000 | 45 ~ 500 |
| 16D | 730 ~ 1450 | 1885～10980 | 44300～211000 | 75 ~ 710 |
| 17D | 730 ~ 960 | 2128～5433 | 53200～168000 | 90 ~ 280 |
| 18D | 730 ~ 960 | 2386～6091 | 63100～199000 | 110 ~ 355 |
| 19D | 730 ~ 960 | 2658～6787 | 74200～234000 | 160 ~ 500 |
| 20D | 730 ~ 960 | 2946～7520 | 86700～273000 | 200 ~ 630 |
| 21D | 580 ~ 960 | 2050～8290 | 79500～316000 | 200 ~ 800 |
| 22D | 580 ~ 960 | 2250～9099 | 92200～363000 | 220 ~ 1000 |
| 23.5D | 580 ~ 960 | 2567～10380 | 112000～443000 | 220 ~ 1400 |
| 25D | 580 ~ 730 | 6794～6464 | 134000～406000 | 355 ~ 800 |
| 26.5D | 480 ~ 730 | 2236～7633 | 132000～483000 | 220 ~ 1120 |
| 28D | 480 ~ 730 | 2496～8522 | 156000～569000 | 315 ~ 1400 |
| 29.5D | 480 ~ 730 | 2771 ~ 9460 | 183000～667000 | 400 ~ 2000 |
Product Features
1. This series of fans is a new type of high efficiency industrial
fan in the field of small flow and medium pressure.
2. The current collector and impeller front plate are processed by
advanced spinning process, and the precision is guaranteed.
3. V-belt and coupling drivetrain fan is equipped with integral
bearing housing, good lubrication, stable operation, long bearing
life.
4. Equipped with tapered sleeve embedded pulley, easy to
disassemble.
5. The collector is equipped with a mounting flange to facilitate
the customer to use the pipeline.
FAQ
1.Q: What parameters need to be provided when you design the industrial centrifugal
fans?
A: Air flow rate(m3/h), Total pressure(Pa) or Static pressure(Pa),
Inlet temperature(°C), Voltage and frequency on the working site.
2. Q:What is your delivery time?
A:15-35workdays, depending on the model of the fan.
3.Q:Are you manufacturer or trading company?
A:We are the professional manufacturer of centrifugal fans , over 65 years production experience and sales experience.
4.Q:What's your MOQ?
A:The MOQ is 1set,but larger quantity, lower price.
5.Q: What’s your warranty?
A: 12 months after arrival of the goods on site.
6.Q:How do you control the product's quality?
A:All the products have quality testing and dynamic balance before
delivery.
