Single Inlet High Volume Explosion Protection Dust Collector Fan
Detail introduction
It’s a high-performance product promoted by the State Economic
Commission and the Ministry of Machinery Industry.
Fans with an impeller diameter of less than 1400 mm operate at a
normal temperature fan system, eliminating the need for additional
bearing cooling devices, reducing the amount of user investment and
maintenance.
When the airflow resistance is increased, the motor load will be
automatically reduced and the motor will not be burnt.
Product features
1. It can output high outgas pressure and can work at higher medium
temperature, suitable for any industrial occasion where high
pressure & high temperature gas needs to be delivered.
2. The tight fit between the components and the good sealing
performance ensure that the output pressure is not reduced.
3. There are a variety of options to choose from.
Technical data
| series | model | Rotation Speed
(r/min) | Total Pressure
(Pa) | Air Capacity
(m³/h) | Power
(kW) |
|---|
| 8-17 | 7.1D | 2900 | 10728～11973 | 768～2919 | 11～18.5 |
| 8D | 2930 | 14297～15680 | 1110～4219 | 22～37 |
| 9D | 2930 | 18308～20250 | 1591～6019 | 37～55 |
Application
1. In the factory, the workshops, warehouses and other departments are
equipped with centrifugal fans, which play a role in ventilation,
ensure the fresh air in the workshop, and help to purify the
working environment and the health of employees. At the same time,
the factory warehouse is equipped with centrifugal fans to dry the
air to ensure that the mechanical equipment or other industrial
products maintain the original quality.
2. Install centrifugal fans in mines and tunnels to re-enter fresh air
and exhaust dirty air to ensure air circulation in the mines and
tunnels.Centrifugal fans can help dust discharge, ensure air
transparency in mines and tunnels, and ensure the health of workers
in mines and tunnels.
3. A centrifugal fan is installed in the cooling tower, which not only
plays the role of ventilation and ensures the normal operation of
the cooling tower, but also plays a positive role in improving the
cooling effect of the cooling tower by the large flow wind
generated by the centrifugal fan.
4. Main ventilator in coal mine is an important equipment to ensure
normal ventilation in underground mine, which not only affects the
production capacity of coal mine, but also is very important to the
safety of mining industry.
5. Centrifugal fans are widely used in boilers and industrial
furnaces. They mainly play the role of ventilation and air
induction. On the one hand, they ensure the environment of the
boiler room or industrial kiln. On the other hand, they allow the
replacement of oxygen-enriched air, which makes the firepower of
the boiler or kiln more fierce and saves coal to a certain extent.
Wait for power resources to reduce enterprise production costs.
FAQ
1. What parameters need to be provided when you design the Heat
Dissipation Power Plant Blower Fan?
Answers: Air flow, total pressure or static pressure, inlet
temperature, local voltage and frequency, Altitude etc.
If there is flammable and explosive gas, or big dust loading in the
medium, please also inform the designer.
2. How about your company’s pre-sales service and after-sales
service?
Answers: Before our cooperation, we have the professional technical
team to help you make the technical solution according to your
working condition, to make sure the centrifugal fan efficiency
operation.
After sales service, we will offer 12 months’ repairing service,
and provide lifelong follow-up services. Besides, our engineers are
available for going abroad to offer the repairing service.
3. Does your company have qualifications?
Answers: SIMO Blower has obtained ISO 9001-2008, CE, TUV
certifications and so on.
